Koller Ice Machine Manufacturer - Walk in Cold Room

Walk in cold room for seafood, meat, ice and other similar items storage
❄ Customizable room size
❄ Precise temperature control
❄ Customizable door type and size

Model:

VCR

MOQ:

1 Set

Certification:

CE, ISO9001

Inquiry

Write a Review

Product Introduction

Koller walk in cold room, maintains a temperature range of -10°C to -20°C and is suitable for storing seafood, meat, ice and other similar items.

Cold storage facility

Cold storage integrated unit

Cold storage for storing vegetables

Fresh flowers are stored in the cold storage

Main Features Of Koller Walk In Cold Room

Intelligent & Automated Control System

Equipped with a fully automatic digital control system for the refrigeration unit, it supports precise temperature management and automatic defrosting functions.

Various Door Types and Sizes.

The cold storage doors come in sliding doors, hinged doors, and glass doors, and the door sizes can be customized according to customer requirements.

Wide Capacity Range & Versatility

The storage capacity ranges from 3 tons to 100 tons, making it suitable for a diverse array of products, including ice, seafood, and meat, etc. It is an ideal solution for both commercial cold chain logistics and industrial processing applications.

Integrated Containerized Design

The cold storage features a standard container-like structure, which allows for factory pre-assembly and complete system integration to guarantee quality. Also, the unit can be easily relocated if needed, offering great operational flexibility.

High-Performance Insulation

The panels are manufactured using high-pressure polyurethane foaming technology, providing superior thermal insulation. This robust structure minimizes cold loss, reduces energy consumption, and ensures the durability of the storage environment under various working conditions.

Reliable Core Components

The refrigeration unit adopts an all-in-one integrated system and is powered by globally recognized compressors, including Copeland and Bitzer. This ensures high operational stability, low failure rates, and extended service life, even in demanding industrial environments.

VCR Walk In Cold Room Parameter Table

Model	VCRXX (Customizable)	Temperature Range	-10℃ ~ -20℃ (adjustable)
Temperature Control Accuracy	±2℃	External Dimensions (L×W×H)	Customizable
Storage Capacity	3 – 100 tons (depending on product density and configuration)	Panel Material	High-pressure polyurethane foam (PU)
Panel Thickness	100mm / 150 / 200mm (customizable)	External Cladding	Corrugated steel / Stainless steel (optional)
Compressor Brand	Bitzer / Refcomp (or equivalent world-class brand)	Cooling Mode	Water Cooling / Air Cooling
Compatible Power Supply	380V/50Hz/3P; 380V/60Hz/3P;220V/60Hz/3P; 415V/50Hz/3P; 440V/60Hz/3P; 220V/60Hz/1P; 220V/50Hz/1P	Refrigerant Options	R507 / R404A / R449
Main Application Scenarios	Storage of ice, ice cream, seafood, and meat, etc.	Disclaimer	All parameters are subject to final design without prior notice

Wide Application of VCR Walk In Cold Room

Ice Cream Hardening & Shaping

Freshly made soft ice cream is rapidly hardened here to develop a dense, stable texture.

Frozen Meat Short-Term Reserve

Provides a stable frozen environment for cuts of meat awaiting further processing or distribution.

Quick-Frozen Dumplings & Dim Sum Finished-Goods Warehouse

Keeps individually quick-frozen items intact without cracking or odor transfer until final sale.

Seafood Chilled Storage Before Processing

Holds thawed seafood at a stable temperature before it enters the processing line.

Pharmaceutical Intermediate Freezing

Maintains cold chain integrity for vaccine intermediates and biological reagents that require -15℃ to -20℃ conditions.

Frequently Asked Questions About Koller VCR Walk In Cold Room

Q: Can you customize the cold room size according to our need?

A: Yes, the cold room size can be designed according to your need.

Q: What compressor brands are equipped for your walk in cold room?

A: Standard fitted with Bitzer or Refcomp well-known European compressors, stable performance, low failure rate and easy global spare parts supply.

Q: Does the machine support multi-voltage power for different countries?

A: Yes, Our standard voltage is 380V/50Hz/3P, but we can also customize other voltages such as 380V/60Hz/3P, 415V/50Hz/3P, 440V/60Hz/3P, 220V/60Hz/3P. For small cold rooms, 220V/50Hz/1P and 220V/60Hz/1P can also be accommodated.

Q: What refrigerant options can I choose?

A: Available refrigerants include R404A, R507 and eco-friendly R449A to match different national environmental regulations.

Q: Do you supply installation guidance and after-sales service overseas?

A: We offer detailed English installation manuals, operation videos, remote online technical support, and long-term spare parts supply for global customers.

Q: How long is the warranty period of the walk in cold room?

A: The whole machine enjoys 1-year full warranty, with core compressors covered by extended brand official warranty.

Q: What’s the production time for the machine?

A: Normally the production time is 30–45 working days for standard designs and 50–90 working days for custom design, both calculated after deposit received.
