Koller provides integrated ice production solutions for businesses looking to supply packaged ice to supermarkets, convenience stores, beverage distributors and other commercial customers. This video shows an ice cup production line operating at a customer facility, illustrating how automated equipment supports the production of packaged ice cups.

The featured video highlights a production target of up to 5,000 ice cups per hour. The achievable output of a complete line depends on the cup size, filling weight, equipment configuration and operating conditions.

How Does an Automated Ice Cup Production Line Work?

A commercial ice cup line typically combines several stages to turn edible ice into a finished retail product.

1. Cube Ice Production

The process begins with an edible cube ice machine. Koller CV series machines offer rated capacities ranging from 500 kg to 20 tons per 24 hours, depending on the selected model.

Automatic water supply, freezing and ice harvesting support continuous production. The appropriate machine capacity should be selected according to the required cup output, ice weight per cup and daily operating hours.

2. Ice Conveying and Transfer

After production, cube ice can be transferred to downstream equipment using a suitable ice conveying system.

Proper coordination between the ice machine and filling equipment helps maintain a steady supply of ice and reduces unnecessary manual handling. Conveyor design depends on the site layout, transfer distance and required production speed.

3. Automatic Cup Filling

The filling system places a controlled quantity of ice into each cup. Depending on the equipment configuration, different filling heads and cup formats can be selected to match the required output.

Consistent filling is important for businesses selling packaged ice by weight or unit, as it helps control product specifications and reduce avoidable material waste.

4. Cup Sealing and Finished Product Handling

After filling, the cups are sealed using a compatible sealing system. Secure seals help reduce leakage during handling and support product protection during chilled distribution.

Additional equipment, such as date coding, outer-lid pressing or finished-product collection, can be incorporated according to the packaging requirements.

The exact workflow and level of automation should be confirmed during project design.

Why Invest in Packaged Ice Cup Production?

For established ice suppliers, ice cups offer another way to serve customers beyond conventional bulk ice or bagged ice.

Retail distribution: Individually packaged ice cups can be supplied to supermarkets, convenience stores and retail outlets.

Beverage and foodservice channels: Restaurants, beverage businesses and catering operators may require convenient, portioned ice products for their daily operations.

Standardized product formats: Consistent cup sizes, filling weights and sealing specifications make it easier to manage orders across different customers.

A more organized production workflow: Automation can reduce repetitive manual handling and help coordinate ice making with downstream packaging.

Whether packaged ice cups are more profitable than bulk or bagged ice depends on local demand, selling prices, cup and film costs, labor, electricity, logistics and equipment utilization. Investors should evaluate these costs before deciding on the production scale.

How to Plan Capacity for a 5,000-Cup/Hour Line

A stated hourly output is only one part of production planning. Before selecting an ice cup line, buyers should establish the required ice weight per cup and the number of operating hours per day.

For illustration, at a target of 5,000 cups per hour:

• 100 g per cup: Approximately 500 kg of ice per hour.

• 200 g per cup: Approximately 1,000 kg of ice per hour.

• 300 g per cup: Approximately 1,500 kg of ice per hour.

These figures represent the theoretical ice requirement at the stated filling rate, not guaranteed production output.

At eight operating hours per day, the corresponding theoretical ice requirements would be 4, 8 and 12 tons respectively. Actual requirements may be higher when accounting for production losses, downtime, cleaning and changes in operating conditions.

This calculation helps buyers avoid a common planning mistake: selecting a cup filling line without checking whether the upstream ice production system can supply enough ice.

Food Hygiene and Packaging Quality

Packaged edible ice is intended for consumption, so hygiene must be considered throughout the production process.

Koller cube ice machines use food-grade SUS304 stainless steel in relevant equipment structures and water-contact components. A complete project should also account for suitable water treatment, sanitation procedures, cleanable product-contact surfaces and hygienic handling during filling and packaging.

The cup material, sealing film and closure method should be compatible with the intended product and storage conditions. Finished products should be stored and transported under appropriate temperature-controlled conditions.

Koller Automated Ice Production Line Solutions

Koller can help customers coordinate cube ice machines with suitable conveying, filling, sealing and supporting equipment to create a production line matched to their business requirements.

The project configuration can be developed around:

• Required hourly and daily production capacity

• Ice weight per cup and cup dimensions

• Number of filling heads and sealing requirements

• Available factory space and production layout

• Water treatment and electrical supply

• Finished-product storage and distribution arrangements

For large-scale projects, matching the capacities of the ice machine, conveying system and packaging equipment is essential. The objective is not simply to install faster machinery, but to create a production workflow in which each stage can support the next.
